Inspec.x L 3.5/105 5.0x
lenses a perfect match for sensors like the popular 12k/5µm and 16k/5µm line-scan sensors
The inspec.x L Series was developed to meet the hig-hest requirements in industrial image processing with very large sensors. This Lens Series shows even contrast and resolution over an image circle of up to 82 mm. The field-proven performance makes these lenses a perfect match for sensors like the popular 12k/5µm and 16k/5µm line-scan sensors.

Very large area-scan sensors also benefit from the high resoluti-on, low distortion and excellent color correction of these lenses.

Key features

- Outstanding MTF performance

- Diffraction limited optical design

- Perfect match with 5 µm pixel size

- Full-metal barrel

- Lockable aperture

- Focal length: 105 mm

- Aperture: 3.5 … 22

- Spectral range: 400-750 nm

- Camera mount: V-groove

Specifications

Family Inspec x. L
Partnumber 0703-102-000-20
Magnification range 4.8 ~ 5.2 x
Magnification 5 x
Image circle 82 mm
Focal length 107.6 mm
F/# 3.5
Wavelength Visible
Type Fixed focal length
Mount V46
Maker Qioptiq
