- Inspec.x L 5.6/105 0.5x
- lenses a perfect match for sensors like the popular 12k/5µm and 16k/5µm line-scan sensors
The inspec.x L Series was developed to meet the hig-hest requirements in industrial image processing with very large sensors. This Lens Series shows even contrast and resolution over an image circle of up to 82 mm. The field-proven performance makes these lenses a perfect match for sensors like the popular 12k/5µm and 16k/5µm line-scan sensors.
Very large area-scan sensors also benefit from the high resoluti-on, low distortion and excellent color correction of these lenses.
Very large area-scan sensors also benefit from the high resoluti-on, low distortion and excellent color correction of these lenses.
Key features
- Outstanding MTF performance
- Diffraction limited optical design
- Perfect match with 5 µm pixel size
- Full-metal barrel
- Lockable aperture
- Focal length: 105 mm
- Aperture: 3.5 … 22
- Spectral range: 400-750 nm
- Camera mount: V-groove
Specifications
| Family | Inspec x. L |
|---|---|
| Partnumber | 0703-084-000-20 |
| Magnification range | 0.4 ~ 0.65 x |
| Magnification | 0.5 x |
| Image circle | 82 mm |
| Focal length | 105.4 mm |
| F/# | 5.6 |
| Wavelength | Visible |
| Type | Fixed focal length |
| Mount | V46 |
| Maker | Qioptiq |
